Aftermarket Pair Of 50A 600V Anderson Style Power Connector Plug With 2 Contacts

Description

This item is a safety quick connect/disconnect connector kits, which allows quick connect and disconnect for winches or other electrical devices. The 4 terminal pins are made of red copper coated with silver, which features strong electrical conductivity and reduces the resistance to guarantee stable voltage and current. This connector is suitable for quick disconnect/ connect is required such as forklift battery charging and plug-in style booster/ jumper cables for vehicle charging.

Features

- Polycarbonate shell which is a versatile and tough plastic makes this connector sturdy and reliable.
- Driver recovery products' quick connector set offers an easy and convenient way to connect and disconnect power to winches, forklifts, chargers, power modules, cars, motorcycles, boats and other electrical devices.
- Silver or plated copper contacts inside housings that strongly force the contacts together
- Stainless steel springs form a rebuts force between the contacts that holds the connector in the mated position.
- Contacts feature a sacrificial tip that allows high current circuit interrupt. Prevents accidental cross mating of circuits.

Specifications

- Color: Red
- Plug: Polycarbonate
- Contact material: Copper, silver plating
- Rated Current (Amperes): 50A
- Rated Voltage (Voltage): 600V
- Contact Barrel Wire Size: 6/10/12AWG (13.3mm⊃2; - 5.3/3.3mm⊃2;)
- Maximum Wire Insulation Diameter:0.44 (inches),11.2(mm)
- AVG Contact Resistance:200(micro-ohms)
- Contact Retention Force :50 (lbf)
- Average contact resistance: 0.05MΩ
- Voltage proof: 2200V (DC)
- Insulation resistance: 500MΩ
- A. No load (Contact/Disconnect Cycles): To 10,000
- B. Under load (Hot Plug 250cycless@120V): 50A
- Avg. Unmating Force: 53N
- Flammability Rating of Housing Material: UL94 V- 0
- Operating temperature range: -20°to 125°

6pcs 50A 600V Anderson Style Power Connector Plug With 2 Contacts
